| Analogue Inputs: |
2x RCA Stereo (A1, A2)
1x Balanced XLR (A3) |
| Digital Inputs: |
2x Coax (D1, D2)
2x Optical (D3, D4)
Bluetooth Audio |
| Analogue Outputs: |
1x Balanced XLR (Pre1)
1x RCA Stereo (Pre2)
1x RCA Stereo (Pre3) |
| Amplifier Output: |
1x Pair of Speaker binding posts (L&R) |
| Other Inputs / Outputs: |
Wi-Fi 4, BLE, 12V Trigger, Wired IR |
| Power: |
IEC C14, Fused 6.2AT |
User Interface |
| Primary Interface: (on unit) |
Dynamic Control Dial (with haptic feedback) to control volume, inputs & power |
| Remote Control: |
Black, 15 button IR remote. Bead blasted & anodised aluminium extruded case with laser etched logo |
Power Amplifier |
| Power Amplifier Technology: |
Dual Mono Euphoria Amplifier |
| Amplifier Class: |
AB |
| Output Power, 8 0hms: (235VAC @ 1% THD, both channels driven) |
105W |
| Output Power, 4 0hms: (235VAC @ 1% THD, both channels driven) |
200W |
| THD+N: (1W @ 1kHz Both Channels driven) |
<0.007% |
| Gain: |
29dB |
| Signal to Noise: (1W/8R 2Vrms A1, both channels driven) |
>85dB |
| Gain Matching: |
<0.5dB |
| Frequency Linearity: (20Hz - 20kHz) |
+-0.25dB |
| Power Supply: |
600VA / 36,400uF per Rail |
Phono |
| Inputs: |
MM |
| Gain MM: |
53dB |
| Gain Adjustment MM: |
Low (-6dB), Mid (0dB default), High (+6dB) |
| Input Impedance MM: |
47k ohms/100pF |
| Gain MC: |
73dB |
| Gain Adjustment MC: |
Low (-6dB), Mid (0dB default), High (+6dB) |
| Input Impedance MC: |
100 ohms/470pF |
| RIAA response accuracy MM/MC: |
+-0.3dB 20Hz - 20kHz |
Rapture DAC |
| DAC Technology: |
Rapture DAC, Dual Mono Balanced |
| Format Support: |
PCM |
| Sampling Rate: |
up to 24bit / 192kHz |
Pre-Amplifier (Amp, Pre1, Pre2) |
| Volume Control Technology: |
Hybrid Digital Analogue |
| Volume Control Matching: |
<0.25dB |
| THD+N: (3.9Vrms, A-Weighted) |
<0.0008% |
| Signal to Noise Ratio: (3.9Vrms, A-Weighted) |
>108dB |
| Maximum Output Level: |
3.9Vrms |
| Supported Features: |
Pre-Output, Line Level Output (Fixed Level), Sub-Woofer Output (Low-Pass Filtered), Intelligent DSP |
Pre-Amplifier (Pre3) |
| Volume Control Technology: |
Digital |
| Volume Control Matching: |
<0.25dB |
| THD+N: (3.9Vrms, A-Weighted) |
<0.003% |
| Signal to Noise Ratio: (3.9Vrms, A-Weighted) |
>108dB |
| Maximum Output Level: |
3.9Vrms |
| Supported Features: |
Pre-Output, Line Level Output (Fixed Level), Sub-Woofer Output (Low-Pass Filtered), Intelligent DSP |
Bluetooth |
| Protocol: |
A2DP Audio Profile |
| Codecs: |
SBC, aptX & AAC |
| Range: |
>15m |
Digital Inputs |
| Coax Inputs: (D1, D2) |
up to 24bit / 192kHz (Stereo) |
| Optical Inputs: (D3, D4) |
up to 24bit / 192kHz (Stereo) |
| HDMI ARC & eARC: |
No |
Analogue Inputs |
| Maximum Input Level: |
6.7Vrms |
| Music Sense: |
A2 Input |
| AV Mode: |
A2 Input |
BluOS Section |
| BluOS Streaming Supported: |
No |
Maestrounite |
| Maestrounite Supported: |
Yes |
| Network Connectivity: |
Bluetooth LE Wi-Fi 4 (Only connects for Over-the-Air Updates) |
| Mobile Application: |
iOS, Android |
| Over-the-Air Updates: |
Firmware Updates are available via the Maestrounite configured Wi-Fi connection. This can be setup to connect & update on user request or during periods of inactivity. |
Other |
| Wired IR Input: |
5 - 14V, Mono 3.5mm jack plug, any polarity |
| 12V Trigger Input: |
5 - 14V, 3.5mm jack dual polarity (On / Standby) |
| 12V Trigger Passthrough: |
3.5mm jack Pass through from input only |
| Nominal Mains Voltage: |
Auto-Selecting Power Supply, 100-120VAC & 220-240 VAC |
| Power Consumption: |
Max 610VA, Standby 0.5W, Network Standby 2W (Standby Plus, allows fast boot) |
Mechanical |
| Construction: |
Extruded and machined Aluminium front & top cover with extruded Aluminium heatsinks. |
| External Dimensions with all accessories fitted:(H x W x D) |
93mm x 432mm x 378mm |
| Weight: |
15.5 kg
|
