Power Output into 8 Ohm. 80W Both Channels Driven, Nominal (THD+N <0.1%)
Power Output into 4 Ohm 130W Both Channels Driven, Nominal (THD+N <0.1%)
Inputs (Digital)
Digital 1 (D1) – Coax SPDIF (up to 192kHz/24bit)
Digital 2 (D2) – Optical SPDIF (max. 96kHz/24bit)
Digital 3 (TV) – Optical SPDIF (max. 96kHz/24bit)
Digital 4 (CD) – Coax SPDIF (up to 192kHz/24bit)
Digital 5 (Bluetooth) – Bluetooth (48kHz/16bit)
Inputs (Analogue)
A1 – Variable Input (no signal sense)
A2 – Fixed Input (with signal sense)
MM (Phono) - RIAA (equalised)
Outputs
1x pair Speaker binding posts (L&R)
1x pair of RCA Analogue (Pre-out/SUB)
3.5mm Stereo mini-jack headphone socket - 7.5Vrms drive suitable for all headphone types including high-impedance
Other
IEC mains power socket (3 pin)/Fuse holder
3.5mm mini-Jack – 12v trigger Input (On / Standby)
IR wired input 3.5mm jack
Construction
Formed Plated steel and bespoke machined anodised aluminium front panel.
Primary Interface (on unit)
Dynamic Control Dial (with haptic feedback) to control volume and inputs
Secondary Interface (on unit)
Standby, Backward, Play/Pause, Forward
Other Interface
IR remote
Bluetooth
A2DP Audio profile /
Codecs - SBC, aptX & AAC
Bluetooth Range - 15m (typical)
Digital Coax Input up to 24bit/192kHz PCM
Digital Optical Input up to 24bit/96kHz PCM
MaestroUnite
System Creation and Control
Advanced System Setting
Over the Air Updates via Wi-Fi
Mains Transformer Rating 400VA
Dimensions (Including Encoder and Connections (W x H x D)) 432 x 76 x 373 mm
Dimensions (Excluding Encoder and Connections (W x H x D)) 432 x 76 x 346 mm
Weight 10.37 kg (22 lb 14 oz)
