Maximum Data Input Rates:
|
24bit Data to 192ks/s: |
AES, SPDIF, TOSLINK |
24bit Data to 192ks/s, MQA, and DSD64: |
10/100 Ethernet |
24bits to 384ks/s, MQA, and DSD64/128 (DoP): |
USB2 Audio |
Low Level Outputs:
|
Line Level Analog: |
4.5Vrms with Bass Management |
Headphone: |
4.5Vrms maximum, 32ohm minimum load |
MM/MC Input:
|
Input Sensitivity: |
MM: 2.5mV to 5mV; MC: 0.25mV to 0.5mV |
Input Load: |
MM: 47K ohms; MC: 50, 100, 500, 1000 |
RIAA Accuracy: |
+/- 0.25dB, 50Hz-15kHz |
THD+N: |
<0.01% 1kHz A-Weighted |
SNR: |
>70dB A-Weighted |
Line Inputs:
|
Maximum Input: |
2.2 Vrms RCA |
Input Impedance: |
10k ohms RCA |
THD+N: |
0.003%, 1kHz |
Dynamic Range: |
110dB, A-weighted 20Hz-20kHz |
Main Outputs:
|
Balanced XLR Output and Impedance: |
5.5Vrms, 100 ohms |
Minimum Load: |
600 ohms |
RCA Output and Impedance: |
2.75Vrms, 100 ohms |
Performance:
|
Dynamic Range: |
126dB A-weighted |
THD+N: |
<0.001% 1W, 1kHz, 4 ohms |
IMD (CCIF): |
<0.001%, 1W, 18.5:19.5kHz 1:1, 4 ohms |
General:
|
Power Usage On: |
20W |
Power Usage Off: |
0W |
Internally Set Operating Voltages: |
100-120VAC, 220-240VAC 50/60 Hz |
Dimensions: |
17.75 W x 15.75 D x 3.25 H inches, 451 x 400 x 83 mm |
Weight: |
14 lbs (6.4 kg) |
